D Subminiature
Panel Mounting
MIL-C-24308 Test Extracts Applicable to Class G Connectors
Pin Front Mounting Pin Rear Mounting
Socket Front Mounting
Figure 1A
Figure 2
Socket Rear Mounting
A
B
PIN
SOCKET
SOCKET
PIN
F
A
C
Pin Front Mounting
Pin Rear Mounting
Pin Rear Mounting
Combination of Mated Connectors
Test Descriptions
Mating/Unmating Force
Contact Retention
Contact Resistance
Vibration
Shock
Durability
Salt Spray
(Corrosion)
Fluid Immersion
Insulation
Resistance
Shell Size
1
2
3
4
5
Max Unmating (LBS)
6
10
17
24
30
Max Mating (LBS) MIL-STD-1344
Method 2013
MIL-STD-1344
Method 2004
MIL-STD-1344
Method 3003
#20 AWG, 7.5 Amp
MIL-STD-1344
Method 3004
MIL-STD-1344
Method 2005 Test Cond. 4
MIL-STD-1344
Method 2004 Test Cond. E
MIL-STD-1344
Method 2016
200 +_ 100 cycles/hour
MIL-STD-1344
Method 1001 Cond. B
MIL-STD-1344
Method 1016
10
17
28
39
49
Contacts shall be retained in their inserts by a 9 pound (minimum) force. The axial displacement of contacts shall not exceed
.012 inch while under load.
After salt spray not to exceed 55 millivolts max.
No damage and no loosening of parts due to vibration. No interruption of eletrical continulty longer than 1 microsecond.
No damage and no loosening of parts. No interruption of eletrical continulty longer than 1 microsecond.
No electrial or mechanical defects after 500 cycles of mating and unmating
No exposure of base metal due to corrosion which will affect performance. Product will meet further test as specified.
20 hours. immersion MIL-H-5606 Hydraulic Fluid
20 hours, immersion MIL-L-23659 Lubricating Fluid
Connectors shall meet mating/unmating force following immersion.
After humidity 1 Megohm (min)
All othe condidtions 5000 Megohm (mm).
Requirement Method
Fig. No. Size Pin (See Note Below) Socket
A
+ .030 (+0.76)
-.000 (-0)
1
1
2
2
2
2
3
3
3
3
A, E
B, C, D
A, E
B, C, D
A, E
B, C, D
A, E
B, C, D
A, E
B, C, D
Standard
Standard
Standard
Standard
Float Mount
Float Mount
Standard
Standard
Rev. Float Mount
Rev. Float Mount
Standard
Standard
Float Mount
Float Mount
Standard
Standard
Rev. Float Mount
Rev. Float Mount
Standard
Standard
.250 (6.35)
.238 (6.04)
.218 (5.53)
.206 (5.23)
.218 (5.53)
.206 (5.23)
-
-
-
-
.340 (8.63)
.343 (8.71)
-
-
-
-
.358 (9.09)
.361 (9.16)
.358 (9.09)
.355 (9.01)
.295 (7.49)
.298 (7.56)
.263 (6.68)
.266 (6.75)
.263 (6.68)
.251 (6.37)
.313 (7.95)
.301 (7.64)
.313 (7.95)
.310 (7.87)
-
-
.120 (3.04)
.120 (3.04)
.120 (3.04)
.130 (3.30)
.120 (3.04)
.120 (3.04)
.120 (3.04)
.130 (3.30)
.295 (7.49)
.283 (7.18)
-
-
-
-
-
-
-
-
B
+ .030 (+0.76)
-.000 (-0)
C
+ .030 (+0.76)
-.000 (-0)
H
+ .030 (+0.76)
-.000 (-0)
F
+_.010 (+_.025)
Pin Front Mounting
Socket Float MountingSocket Float Mounting
Socket Reverse
Float Mounting
Socket Reverse
Float Mounting
Pin Front Mounting
Pin Rear Mounting
Socket Front Mounting
Figure 1B
Figure 3
Socket Rear Mounting
C
H
PIN
.187 (4.75) MAX. ROLL
OVER TYPICAL
.145 (3.70) MAX. ROLL
OVER TYPICAL
WASHER
.031 (0.80) NOM. THICK
NOTE:
1. A, B, C and H are dimensions betwen panels and represent the
recommended limit to be used in the design of the connector
mounting method.
2. It is recommended that only one assembly, either pin or socket,
be float mounted.
3. Standard pin assemblies contained .015 (0.38) thick front
shells on E and A sizes; .024 (.061) thick front shells on B, C,
and D sizes.
4. Standard connectors accommodate a #4 screw. Float mount
connectors accommodate a #2 screw.
RIVET
.031 (0.80) NOM. THICK
SOCKET
SOCKET
C
B
WASHER
RIVET
PIN
