SPRING-LOADED CONNECTORS
Discrete Spring-Loaded Contacts
www.mill-max.com
516-922-6000
15
0900-0-00-00-00-00-11-0
Short Stroke, Surface mount
Lowest profile
0900-0
0913
A
.072 DIA.
.072 DIA.
.028
.028
.016
.016
.198
.198
.055
.055
.0275
.0275
.064 DIA.
.064 DIA.
.059 DIA.
.059 DIA.
.042 DIA.
.042 DIA.
0907-X-15-20-75-14-11-0
Standard Stroke, Surface mount
High profile
0907-0
9
A
.072 DIA.
.072 DIA.
.028
.028
.016
.016
.106
.106
.055
.055
.0275
.0275
.064 DIA.
.064 DIA.
.059 DIA.
.059 DIA.
.042 DIA.
.042 DIA.
0900-X-00-00-00-00-11-0
Standard Stroke, Surface mount
Low profile
0900-1
4
0925-0-15-20-73-14-26-0
Standard Stroke
Surface mount
0913-0-15-20-77-14-11-0
Long Stroke
Surface mount
.028
.028
.016
.016
.638
.638
.0275
.0275
.055
.055
.072 DIA.
.072 DIA.
.064 DIA.
.064 DIA.
.059 DIA.
.059 DIA.
.042 DIA.
.042 DIA.
.693
.693
0905-0-00-00-00-00-11-0
Standard Stroke, Surface mount
Highest Profile
0905
0925
Basic Part
Number
Length
A
0900-1
0900-2
0900-3
0900-4
.177
.197
.217
.236
Basic Part
Number
Length
A
0907-0
0907-1
0907-2
0907-3
0907-4
0907-5
0907-6
0907-7
0907-8
0907-9
.255
.275
.295
.315
.335
.350
.370
.390
.410
.430
ORDER CODE: 09XX - X - 15 - 20 - 7X - 14 - XX - 0
Spring Number
MA
TERIAL SPECIFICATIONS:
SLEEVE & PLUNGER MATERIAL: Copper Alloy
SPRING MATERIAL: Beryllium Copper
SLEEVE & PLUNGER FINISH: 20 μ” Gold over Nickel
SPRING FINISH: 10 μ” Gold over Nickel
DIMENSION IN INCHES:
TOLERANCES ON: LENGTHS: ±.006
DIAMETERS: ±.002
ANGLES: ± 2°
MECHANICAL & ELECTRICAL SPECIFICATIONS:
DURABILITY: 1,000,000 cycles
CURRENT RATING: 2A continuous, 3A peak
CONTACT RESISTANCE: 20 mΩ max.
73, 74, 75, 77 Springs are not Interchangeable
RoHS
2002/95/EC
73
74
75
77
.0275
.0275
.0275
.045
.055
.055
.055
.090
60 g
50 g
60 g
60 g
25 g
15 g
25 g
25 g
SPRING
NUMBER
Mid.
STROKE
Max.
STROKE
FORCE @
Mid. Stroke
Initial Force
(Pre-load)
0934-0-15-20-74-14-26-0
Standard Stroke
Surface mount
0934
0936
0928-0-15-20-77-14-11-0
Long Stroke
Surface mount
0936-0-15-20-75-14-11-0
Standard Stroke
Surface mount
0928
0927-0-15-20-75-14-11-0
Standard Stroke
Surface mount
0927
.197
.197
.288
.288
.072 DIA.
.072 DIA.
.064 DIA.
.064 DIA.
.059 DIA.
.059 DIA.
.042 DIA.
.042 DIA.
.028
.028
.016
.016
.198
.198
.045
.045
.090
.090
