Part Number:
0787882423
Status:
Active
Overview: Milli-Grid™ Connector System
Description: Milli-Grid™ Receptacle, Surface Mount, Vertical, Top Entry, without Plastic Pegs, with
Cap, Tube, 2.50µm Tin (Sn), 24 Circuits, Lead-Free
Documents:
Drawing (PDF) Packaging Specification PK-78788-003 (PDF)
Product Specification PS-78788-001-001 (PDF) RoHS Certificate of Compliance (PDF)
Agency Certification
CSA LR19980
UL E29179
General
Product Family PCB Receptacles
Series 78788
Application Board-to-Board, Signal
Overview Milli-Grid™ Connector System
Product Name Milli-Grid™
UPC 889056494762
Physical
Circuits (Loaded) 24
Circuits (maximum) 24
Color - Resin Black
Durability (mating cycles max) 30
Flammability 94V-0
Glow-Wire Compliant No
Lock to Mating Part None
Material - Metal Copper Alloy
Material - Plating Mating Tin
Material - Resin High Temperature Thermoplastic
Net Weight 0.679/g
Number of Rows 2
Orientation Vertical
PCB Locator No
PCB Retention None
Packaging Type Tube
Pitch - Mating Interface 2.00mm
Plating min - Mating 2.500µm
Polarized to Mating Part No
Polarized to PCB No
Robotic Placement Pick and Place Cap
Temperature Range - Operating 0°C to +105°C
Termination Interface: Style Surface Mount
Electrical
Current - Maximum per Contact 1.0A
Voltage - Maximum 125V AC (RMS)/DC
Solder Process Data
Duration at Max. Process Temperature (seconds) 010
Lead-freeProcess Capability REFLOW
Max. Cycles at Max. Process Temperature 001
Process Temperature max. C 260
Material Info
Series image - Reference only
EU ELV
Compliant
EU RoHS China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS Green Image
ELV Compliant
RoHS Phthalates Not Contained
Search Parts in this Series
78788 Series
Mates With
Milli-Grid™ Header 87758 , 87759 , 87760
, 87831 , 87832 , 87833 <br> Milli-Grid™
Low-Halogen Header 151117 , 151118 ,
151119 , 151120
