Bezeichnung :
description :
A
9,00 ± 0,1
mm
B
16,0 ± 0,2
mm
+ 0
1
- 0
0
D
4,00 ± 0,1
mm
E
2,00 ± 0,1
mm
F
1,75 ± 0,1
mm
G
9,00 ± 0,1
mm
H
3,50 ± 0,1
mm
a 330,0 ± 2,0 mm
b 21,00 ± 0,8 mm
c 13,00 ± 0,5 mm
d 100,0 ± 1,0 mm
MST 04-10-11
MST 03-12-10
RT 03-02-24
MST 02-02-27
JH 00-12-06
Name Datum / date
Version 2
Version 3
Version 4
Version 5
mm
1,50
C
Spezifikation für Freigabe / specification for release
Kunde / customer :
Artikelnummer / part number :
D-74638 Waldenburg · Max-Eyth-Strasse 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
Datum / date Unterschrift / signature
Würth Elektronik
Kunde / customer
http://www.we-online.de
..................................................
...........................................
Geprüft / checked Kontrolliert / approved Änderung / modification
Version 1
..............................................................................
ürth Elektronik eiSos GmbH & Co. KG
..............................................................................
SPEICHERDROSSEL WE-PD
POWER-CHOKE WE-PD
I Rollenspezifikation / Tape and reel specification : Gurtspezifikation / Tape specification:
DATUM / DATE : 2004-10-11
Rollenspezifikation / Reel specification:
Freigabe erteilt / general release:
7447782
H
G
Ø c
a
d
b
A
B
FEDøC
The force for tearing off cover tape is
10 to 130 grams in arrow direction
165 to 180°
feeding direction
