Qty Reference Value Description Case Manufacturer PN
2 C125-126 20pF Ceramic 0603 GRM1885C1H200JA01D
1 C164 150pF Ceramic 0603 C1608C0G1H151J
1 C151 1nF Ceramic 0603 C0603X7R500-102KNE
1 C102 10nF Ceramic 0603 C0603X7R500-103JNE
1 C163 15nF Ceramic 0603 ECJ1VB1H153K
1 C184 220nF Ceramic 0603 GRM188R71A224KA01D
5 C117 C119 0.1uF Ceramic 0603 C0603Y5V250-104ZNE
C121 Ceramic 0603
C123-124 Ceramic 0603
4 C101 C103 1uF Ceramic 0603 C0603Y5V250-105ZNE
C120 C172 Ceramic 0603
1 C118 10uF Ceramic 0805 C0805X5R6R3-106KNE
1 R1 0 1/16 W 0603 CR0603-16W-000T
2 R180-181 22 1/16 W 0603 CR0603-16W-220JT
3 R3 R6-R7 180 1/16 W 0603 CR0603-16W-181JT
4 R103-105, R171 825 1/16 W 0603 CRCW0603825RFKEA
1 R183 1.5K 1/16 W 0603 CR0603-16W-152JT
1 R144 4.7K 1/16 W 0603 CR0603-16W-472JT
1 R172 3.92K 1/16 W 0603 ERJ3EKF3921V
2 R151 R184 47K 1/16 W 0603
CRCW060347K0FKEA
1 R2 DNI 1/16 W 0603
2 R4, R5 0 1/16 W 0402
CR0402-16W-000T
1 IC2 - ATMEL AVR 64 PIN QFN AT90USB1287-64QFN
1 Y121 16MHz Crystal SMD ABM3B-16.000MHZ-B2-T
1 U1 3.3V Regulator SOT-23-5 MIC5219-3.3YM5 TR
1 U6 - ATMEL CryptoCompanion 8ld SOIC ATSC018-SU-CM
1 LEDP BLUE LED 0603 MB1111C-TR
3 LED1-3 RED LED 0603 BR1111C-TR
2 D181-182 - ESD Suppressor 0603 PGB1010603MR
1 D1 DIODE Schotkky SOD-323 NSR1020MW2T1G
1 D2 DIODE Schotkky SOD-123 MBR0520L
1 USB WM17117-ND TYPE A USB RT ANG.
48037-0001
1 L161 - Ferrit Bead 0603 MI0603J601R-10
1 Q1 NPN Transistor SOT23-3 MMBTA42LT1G
1 H2 0.1" Pitch JTAG 2x5 Male Header RA TSW-105-16-L-D-RA
1 J1 0.1" Pitch PORT-D Interface 2x5 Male Header PBC05DAAN
1 B121 - Buzzer SMD SMT-0540-S-R
2 B151 - Push Button SMD PTS635SL25SMTR LFS
1 K1 - DPDT switch SMD CAS-220TA
AT88Microbase BOM
MISC
DIODE
CAPACITOR
IC
RESISTOR
