Catalog 82068 Dimensions are shown for Dimensions are in inches and Canada: +1 (905) 475-6222 UK: +44 (0) 800-267666
Revised 4-12 reference purposes only. millimeters unless otherwise Mexico/C. Am.: +52 (0) 55-1106-0800 France: +33 (0) 1-3420-8686
Specifications subject specified. Latin/S. Am.: +54 (0) 11-4733-2200 Netherlands: +31 (0) 73-6246-999
www.te.com to change. USA: +1 (800) 522-6752 Germany: +49 (0) 6251-133-1999 China: +86 (0) 400-820-6015
AMPLIMITE Subminiature D Connectors
Note: All part numbers are RoHS compliant.
Cable Connectors
HDE-20 Basic Shielding Hardware Kits (Continued)
Each kit contains:
■ Connector
■ Inner shield
■ Outer shield
Ferrules must be purchased separately.
Material and Finish:
Connector Shell—Steel, tin plated
Connector Insert—94V-0 rated
thermoplastic, black
Shield—Steel, tin plated
Contacts—Phosphor bronze
Contact Finish—Duplex plated:
A—.000030 [0.00076] gold on mating
end, tin on termination end, with entire
contact nickel underplated
B—Gold flash on mating end, tin on
termination end, with entire contact
nickel underplated
Related Product Data:
Contact Arrangements—page 40
Performance Characteristics—
page 41
Application Tooling—pages 121-123
Mateable Connectors:
HDP—pages 90-97
HD-20 Board Mount—pages 54-71,
78-85, 87-89
Mating Hardware—pages 146-150,
153, 155
Mating/Panel Mounting—page 42
Receptacle
.243
[6.17]
Typ.
Rcpt. Connector
Ferrule (Must
be Purchased
Separately)
Outside
Shield
I
nside
S
hield
View of Rear Shell
(With Shields Removed)
.086
[2.18]
Max.Typ.
.
509
[
12.93]
Max.
.
112
[
2.84]
Typ.
.109
[2.77]
T
yp.
C
D
.490
[12.45]
Max.
.
395
[
10.03]
D
ia.
.377
[9.58]
.
120
[
3.05]
2
Holes
Dia.
Technical Documents:
Product Specifications—
108-40011
108-40030
Application Specifications—
114-40002
114-40003
114-40006
Instruction Sheet—408-9010
Note: Instruction Sheets for TE Tooling
are packaged with the tooling. For
additional information call the Tooling
Assistance Center: 1-800-722-1111.
Connector Part Numbers
Recommended Max. Contact Contact Contact
No. of Cable Inner
Contact
I.D. No. 1 I.D. No. 2 I.D. No. 3
Shell
Contact
Dimensions
Outer Cable
Finish
for 30-26 AWG for 26-22 AWG for 22-20 AWG
Size
Pos.
CD
Dia. Bundle
(Plating
[0.05-0.15mm
2
] [0.15-0.4mm
2
] [0.4-0.6mm
2
]
Range Dia.†
Code)
Wire Wire Wire
Receptacle Receptacle Receptacle
1.520 .678 .165-.455 .350
A—747516-7 747516-8
19
38.61 17.22 4.19-11.56 8.89
B—747516-9 —
1.520 1.002 .165-.455 .350
A—747532-7 —
2 15
38.61 25.45 4.19-11.56 8.89
B—747532-8 —
1.520 1.550 .165-.455 .350
A—747548-8 —
3 25
38.61 39.37 4.19-11.56 8.89
B—747548-9 —
1.867 2.205 .338-.562 .450
4 37
47.42 56.01 8.59-14.28 11.43
B 747564-8 747564-9 —
Note: Components of the kits are shipped unassembled and bulk-packaged in quantities of 100 pieces.
†Maximum cable diameter after jacket and braid removed.
