AMPLIMITE Subminiature D Connectors
Note: All part numbers are RoHS compliant.
Cable Connectors
HDE-20 All-Plastic IDC Connectors
Notes: 1. All connectors are preloaded with insulation displacement contacts. Pins in plug connectors and sockets in
receptacle connectors. Contacts accept a max. wire insulation thickness of .015 [0.38] and a max. wire
insulation dia. of .060 [1.52].
Notes: 2. HDE connectors are designed for terminating solid or stranded (7-strand max.) wire.
3. Individual conductor strands should be larger than .005 inch [0.127] diameter.
4. Extraction Tool Part No. 91232-1 (Instruction Sheet 408-6631) is used to remove pin or socket contacts.
5. For terminating more than one wire, or a drain wire, use crimp contacts on page 121.
Connector Part Numbers
Contact
Contact Contact
No. of Identification Identification
Shell
Contact
Dimensions
Finish
No. 1 No. 2
Size
Positions
AB
(Plating
for 30-26 AWG for 26-22 AWG
Code)
[0.05-0.15mm
2
] Wire [0.15-0.4mm
2
] Wire
Plug Plug
1.213 .984
A—745203-2
19
30.81 24.99
B—1-745203-1
1.541 1.312
A—745207-7
2 15
39.14 33.33
B——
2.090 1.852
A 745211-9 745211-7
3 25
53.09 47.04
B—745211-8
2.732 2.500
A—745215-7
4 37
69.39 63.50
B——
Material and Finish:
Housing—94V-0 rated thermoplastic,
black
Contacts—Phosphor bronze
Contact Finish—Duplex plated:
A—.000030 [0.00076] gold on mating
end, tin on termination end, with entire
contact nickel underplated
B—Gold flash on mating end, tin on
termination end, with entire contact
nickel underplated
Related Product Data:
Contact Arrangements—page 40
Performance Characteristics—
page 41
Interchangeable Crimp Snap-In
Contacts—page 121
Application Tooling—pages 121-123
Mateable Connectors:
HDP—pages 90-97
HD-20 Board Mount—pages 54-71,
78-85, 87-89
Mating/Panel Mounting—page 42
Cable Clamps—pages 132, 133, 135-
137, 139, 140, 144, 145
Mating Hardware—pages 146-150,
153, 155
Technical Documents:
Product Specification—108-40011
Application Specifications—
114-40002
114-40003
Instruction Sheet—408-6621
Note: Instruction Sheets for TE Tooling
are packaged with the tooling. For
additional information call the Tooling
Assistance Center: 1-800-722-1111.
Plug
Molded Cavity
Indentification &
AMP Trademark
.120
[3.05]
2 Holes
.109
[2.77]
Ref.
B
A
.
112
[
2.85]
T
yp.
.
509
[
12.93]
.860
[21.84]
.230
[5.84]
.080
[2.03]
M
ax.
Dia.
R
ef.
P
lug
