AMPLIMITE Subminiature D Connectors
Note: All part numbers are RoHS compliant.
Cable Connectors
Hardware (Continued)
Material and Finish:
All Parts—Cold rolled steel, zinc
plated clear or yellow chromate
Related Product Data:
Connectors used with:
HDE Metal-Shell or All-Plastic—
pages 112-115
HDF Metal-Shell or All-Plastic—
pages 125 & 126
HDP Metal-Shell—pages 90-102
HD Board Mount—pages 54-71,
78-85, 87-89
Technical Documents:
Instruction Sheet—408-7837
Nut Driver, Part No. 811262-1
(Used for assembling female screwlocks
to connector flange)
Individual Screwlocks
(Washers and Nuts not included)
Connector Dimension Thread
Kit Number
U
sed with
S
tyle
C
Size
F
inish
I
ndividual Bulk Packed
▲▲
HD All-Plastic Right-Angle .250
Y
ellow Chromate 5207952-1 —
P
lugs and Receptacles
(
A)
6
.35
4
-40
Clear Chromate 5207952-3 —
HDE Metal-Shell or All-Plastic .250
Yellow Chromate 5745563-1 5745563-1
Plugs and Receptacles
(B)
6.35
4-40
Clear Chromate 5745563-3 5745563-4
Yellow Chromate 5205817-1 5205817-2
HDP or HDF Metal-Shell or
.312
4-40
Clear Chromate 5205817-3 5205817-4
All-Plastic Plugs and (B)
7.93
M3
Yellow Chromate 5207872-1 —
Receptacles
(Metric)
Clear Chromate 5207872-3 —
HD or HDF All-Plastic Plugs
4-40
Yellow Chromate 5207719-1 5207719-2
and Receptacles with
.560
Clear Chromate 5207719-3 5207719-4
Integral Standoffs
(B)
14.22
*2-56* Clear Chromate 5747223-3 —
* 2-56 is the male thread size. The female thread size is 4-40.
▲▲
Each part is individually bulk packed for multiple kit orders.
Notes: 1. All parts are packaged unassembled.
2. Each female screwlock kit is comprised of two assemblies as illustrated above.
3. One or two flat washers may be required for panel thicknesses less than .060 [1.52]. Female screwlocks
are not recommended for panel thicknesses greater than .060 [1.52].
Notes: 4. Female screwlocks with 2-56 thread size are to be used with cable clamps with mounting flanges. Female
screwlocks with 4-40 and M3 (Metric) thread sizes can be used with all other cable clamps.
Notes: 5. Female screwlocks mate with male screw retainers (pages 146 and 147).
6. Short female screwlocks cannot be used with HDF connectors (pages 125 & 126)
Connector Dimension Thread
Screwlocks
Used with
Style
C Size
Finish
Individual Bulk Packed
▲▲
HD All-Plastic Right-Angle .250
Yellow Chromate 5207953-2 —
Plugs and Receptacles
(A)
6.35
4-40
Clear Chromate 5207953-3 —
Clear Chromate
— 5205818-3
▲▲ ▲▲
4-40 5748558-3 5748558-4
.312
Yellow Chromate 5748270-2 5205818-2
▲▲ ▲▲
HDP or HDF Metal-Shell or (B)
7.93
**M2.6**
All-Plastic Plugs and
(Metric)
Clear Chromate 5749765-3 —
Receptacles
***M3***
(Metric)
Clear Chromate 5747404-3 —
.185
(Special)
4.70
4-40 Clear Chromate 5747877-3 —
▲▲
Each part is individually bulk packed for multiple kit orders.
▲▲ ▲▲
With captivated star washer. No additional hardware included.
†Part No. 5748270-2 Dimension .158 [4.01]
***M2.6 is the female thread size. The male thread size is 4-40.
***M3 is the female thread size. The male thread size is 4-40.
Lock Washer
Flat Washers
(See Note 3.)
Style (B). Standard and
Long Female Screwlocks Kit
Metal-Shell or
All-Plastic
Plug or
R
eceptacle
(
Shown for Ref. only.
S
ee Notes 4 & 5.)
S
tyle (A). Female
S
crewlocks Kit
S
quare
N
ut
Hex Nut
Flat Washers
.188†
[4.78]
.188†
[4.78]
.250
[6.35]
C
C
Female Screwlocks
for Metal-Shell and
All-Plastic Connectors
(HDE, HDF, HDP)
†Part Number 5748270-2
Dimension .158 [4.01]
