AMPLIMITE Subminiature D Connectors
Cable Connectors
Accessories
Numerous accessories are
available for strain relief and
cable clamping, shielding,
c
onnector-to-connector
mating, connector-to-
connector pc board
mounting, and keying.
These accessories are
illustrated and tabled on
the following pages.
To help discern the
accessories available
for a particular connector
type, refer to the Product
Selection Guide at the
beginning of the connector
section. Also, the connector
the accessory is used with
is listed under the Related
Product Data heading next
to the accessory listing.
Section Contents
Unshielded Cable Clamps
Universal Cable Clamps for Jacketed Cable . . . . . . . . . . . . 132
One-Piece, All-Plastic Cable Clamp. . . . . . . . . . . . . . . . 133, 134
Straight/90° Low Profile Cable Clamps . . . . . . . . . . . . . . . . . . 135
Slide-On Back Covers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Box and Lid, Straight/90° Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Clam Shell, Straight/45° . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Straight Exit, Dataphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Straight Exit for Jacketed Cable (Two-Piece) . . . . . . . . . . . . 139
Straight/90° Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Shielded Cable Clamps
Straight Exit RFI/EMI Shields for Jacketed Cable
(HDE, HDP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Straight/90° Exit RFI/EMI Die Cast Shields for
Jacketed Cable (HDE, HDP) . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Crimp and Split-Ring Ferrules . . . . . . . . . . . . . . . . . . . . . . 143-145
Hardware
Commoning Strip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Male Screw Retainers for Metal-Shell Connectors
(HDE, HDP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Male Screw Retainers for All-Plastic Connectors (HDE) . . . 147
Male Screw Retainers for Metal-Shell and All-Plastic
Connectors (HDF). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Female Screwlocks for Metal-Shell and All-Plastic
Connectors (HDE, HDF, HDP). . . . . . . . . . . . . . . . . . . . . . . . . 148
Slide Latches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149, 150
Slide Latch Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Locking Post Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Spring Latches (Two-Piece) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Latching Blocks (HDE, HDF, HDP, HD) . . . . . . . . . . . . . 153, 154
Standoff Bushings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Keying Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
EMI/RFI Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
