AMPLIMITE Subminiature D Connectors
Note: All part numbers are RoHS compliant.
Cable Connectors
HDE-20 Application Tooling
A modular interchangeable head provides versatility to these tools. Along with the head
used to terminate Subminiature D connectors, heads are available to terminate other TE
product lines.
The head used to terminate the Subminiature D, HDE connectors can be used with a
manual pistol grip tool, an air pistol grip tool and a bench mount power assembly. These
tools terminate one unstripped wire per cycle and index the connector to the next
terminating position. The head rotates to permit optimum access to the wiring area.
Hand Tools with
Modular Heads
Technical Documents:
Instruction Sheets—
408-6790
408-9414
408-6789
Note: Instruction Sheets for TE Tooling
are packaged with the tooling. For
additional information call the Tooling
Assistance Hotline: 1-800-722-1111.
H
andle and Head Tool Assembly No. 608868-1
Handle No. 58074-1
Head Assembly No. 58063-2
This tool is manually actuated, using
modular heads.
Bench Mount
Pneumatic Power Assembly
Bench Mount
Electric Power Assembly
Bench Assembly No. 58338-1
Head Assembly No. 58063-2
This tool is air actuated with
either a foot or knee switch.
Head Assembly No. 58063-2
This tool electrically powered
and actuated by a foot switch.
Manual Pistol Grip Tool
Air Pistol Grip Tool
Handle No. 58075-1
H
ead Assembly No. 58063-2
Air actuated, utilizing modular heads.
Bench Mounted
Tools with
Modular Heads
