Tri-Start and Specials
insert availability and identification
Contact Size
Shell Military Service Total 22D 20 16 12 12 10 8 8††
Size/Arrg. Shell Crimp Hermetics* Rating Contacts (Coax) (Power) (Coax) (Twinax)
23-35 H X P M 100 100
23-53 H X P I 53 53
23-54 ■ H ✦ M5340 94
23-55 H ✦ P I 55 55
25-4 J X P I 56 48 8
25-7 J ✦ Twinax 99 97 2
25-8★ J ✦ Twinax 8 8
25-11*** J ✦ N11 2 9
25-17 ■ J ✦ M4236 6
25-19★ J X P I 19 19
25-20*** J ✦ N30 1013 4 3
25-24★ J X P I 24 12 12
25-26 ■ J ✦ I25 16 5 4
25-29★ JX I 29 29
25-35 J X P M 128 128
25-37★■ J ✦ I37 37
25-41 ■ J X N/Inst. 41 22 3 11 2 3
25-43 J ✦ I43 2320
25-46 J ✦ I46 404 2†
25-61 J X P I 61 61
25-90 J X I 46 40 4 2
25-F4 ■ J ✦ M/I 66 49 13 4
TRI-START ARRANGEMENTS, CONT.
Contact Size
Shell Military Service Total Comments 22D 20 16 12 8††
Size/Arrg. Shell Crimp Hermetics* Rating Contacts (Twinax)
9-2 A X I 2 formerly Pyle 2
15-4 D X II 4 formerly Pyle 4
15-25 D X M 25 formerly Pyle 22 3
17-20 E X M 20 formerly Pyle 16 4
21-12 G X I 12 formerly Pyle 3 9
21-21 G X M/Inst. 41 improved sealing 32 9
21-99 G X M 16 formerly Pyle 5 11
25-92 J X M 101 formerly Pyle 92 9
25-97 J X M 42 formerly Pyle 26 3 13
SPECIAL ARRANGEMENTS (Not Mil-Spec Qualified)
Contact Size
Shell Service Total 22D 20 8 4 0
Size/Arrg. Crimp Hermetics* Rating Contacts
25-16 X M 8 6 2
25L-3 X II 3 1 2
25L-7 X II 7 7
33-3 X II 3 1 2
33-5 X II 5 5
33-6 X II 6 2 4
37-5 X II 4 4
SPECIAL ARRANGEMENTS (Not Mil-Spec Qualified)
(insert arrangements requiring non-standard shells or larger contacts)
X Completely tooled.
• Majority of tooling is completed (contact Amphenol
Aerospace for availabilty).
✦ Not tooled for 02-R.
P Pin inserts only (contact Amphenol Aerospace for
socket availability).
★ Ground plane proprietary option available.
Arrangement 9-5 is exclusively ground plane type.
■ Not Mil-Qualified.
* Hermetic inserts - solder termination standard.
(Contact Amphenol Aerospace for optional PCB or
eyelet termination).
** Two size 16 contacts dedicated to fiber optics.
Consult Amphenol Aerospace catalog 12-352
for fiber optic information.
*** For use in MIL-STD-1760 applications (pgs. 31 & 32).
† For RG 180/U and RG 195/U cables only.
†† Size 8 Coax and Twinax are interchangeable.
Note: 25L-3 and 25L-7 require longer shells.
