Tri-Start
how to order – (Amphenol
®
TV, metal)
how to order – (Amphenol
®
TV26 CLUTCH-LOK
®
)
Connector Type
TV designates Tri-Start Series Connector
TVP designates back panel mounted receptacle
TVS designates 200°C rated
TVPS designates back panel mounted, 200°C rated receptacle
MTV designates CLUTCH-LOK connector with “MS” stamping
(Note: remove dashes in how to order part number when
ordering CLUTCH-LOK)
Shell Style
00 designates wall mount receptacle
01 designates line receptacle
02 designates box mount receptacle
06 designates straight plug
26 designates proprietary CLUTCH-LOK high vibration straight
plug (available in service classes RK and RS only)
07 designates jam nut receptacle
09 designates flange mounted plug
IY designates solder mounted receptacle, hermetic only
HIY designates weld mounted receptacle, hermetic only
Service Class
RX alternate finish, requires special variation suffix. Example:
non-conductive, anodic coated aluminum is defined by
variation suffix 005. Consult Amphenol, Sidney NY for
details, options and availability of non-cadmium or nickel
finishes.
RF electroless nickel plated aluminum, optimum EMI
shielding effectiveness –65dB @ 10GHz specification
min., 48 hour salt spray, 200°C
RGF** electroless nickel plated ground plane aluminum, 200°C
RGW** olive drab cadmium plated ground plane aluminum, 175°C
RK* corrosion resistant stainless steel, firewall capability, plus
500 hour salt spray resistance, EMI –45 dB @ GHz
specification min., 200°C
RW corrosion resistant olive drab cadmium plate aluminum,
500 hour extended salt spray, EMI –50 dB @ 10 GHz
specification min., 175°C
RQF same as RF except with Quadrax contacts
RGQF same as RGF except with Quadrax contacts
RGQW same as RGW except with Quadrax contacts
RQK same as RK except with Quadrax contacts and not
firewall capable
RQW same as RW except with Quadrax contacts
Y hermetic seal, passivated stainless steel, 200°C
RS* (non-hermetic connectors), nickel plated stainless
steel, optimum EMI shielding effectiveness –65dB
@ 10 GHz specification min., 500 hour salt spray,
200°C, firewall barrier
YN (hermetic connectors), nickel plated stainless steel,
200°C
DN Durmalon plated, Nickel-PTFE alternative to Cadmium.
Corrosion resistant, 1,000 hour salt spray, EMI- 50dB at
10GHz specification min., 175 degrees
Shell Size
MIL-DTL-38999, Sizes 9-25.
TVPS 00 RF - 9 -35 P B (XXX)
Connector Type
Shell Style
Service Class
Shell Size
Insert Arrangement
Contact Type
Alternate Positions
Special Variations
Proprietary Part Number
* Coaxial arrangements are not available in these classes.
** For more information on Coax/Triax/Twinax Ground Plane
Connectors see page 49.
A B C D E F G H J MIL Shell Size
9 11 13 15 17 19 21 23 25 Amphenol
Shell Size
Insert Arrangement
MIL-DTL-38999, see insert arrangement charts, pgs. 6 & 7.
Contact Type
P designates pin contacts
S designates socket contacts
Alternate Positions
Locksmith keying - rotation of minor keys. See page 8.
“N” not required for normal position.
Special Variations
Consult Amphenol Aerospace, Sidney, NY for variations.
Amphenol® Tri-Start Connectors (metal) can be ordered by coded part number.
Ordering procedure is illustrated by part number TVPS00RF-9-35PB( ) as shown below:
