High Speed Fiber Pigtailed InGaAs p-i-n Photodiode
13PD100-F
The 13PD100-F is an InGaAs photodiode with a 100µm-diameter photosensitive region
packaged in a co-axial fiber pigtailed module. Modules are available with stock or customer-
supplied fiber in single or multi-mode versions. The coaxial package offers streamlined design
and strain-relief for the fiber. Planar semiconductor design and dielectric passivation provide
superior noise performance. Reliability is assured by hermetic sealing and a 100% purge burn-in
(200
o
C, 15 hours, V
r
= 15V). A low backreflection (-LBR) option is available.
Features
Planar Structure
Dielectric Passivation
100% Purge Burn-In
High Responsivity
Device Characteristics
Parameters Test Conditions Min Typ Max Units
Operating Voltage - - - -20 Volts
Dark Current -5V - 0.5 2 nA
Capacitance -5V - 1.15 1.9 pF
Responsivity 1300nm 0.65 0.80 - A/W
Rise/Fall - - - 0.5 ns
Frequency Response (-3dB) - 1.0 - GHz
Backreflection (STD) -20 dB
(LBR) -55 dB
Absolute Maximum Ratings
Reverse Voltage 30 Volts
Forward Current 5 mA
Reverse Current 500 µA
Operating Temperature -40
o
C to + 85
o
C
Storage Temperature -40
o
C to + 85
o
C
Soldering Temperature 250
o
C
829 Flynn Road, Camarillo, CA 93012 tel (805) 445-4500 fax (805) 445-4502.
