Name: 87437-0243
SKU: 87437-0243
Price: 0.22420 USD
Availability: InStock

Datasheet for 76650-0236

General Information

Kit Part Number: 76650-0236

Connector Type: Wire-to-Board

Solution: Off the Board

Molex Family: PicoBlade™, PanelMate™, Pico-SPOX™, CLIK-Mate™ 1.25mm

Certificates: N/A

Country of Origin: Kit assembled in U.S.A

Specifications

Circuit Size: 2, 4, 6

Current Rating: 1.5-3A, 1A

Mounting Style: PCB Through Hole, SMT (Surface Mount Technology)

Orientation: Plugs, Receptacles, Right Angle Headers, Vertical Headers

Pitch: 1.25mm (.049"), 1.50mm (.098")

Tool Included: No

Voltage Rating: 125V, 30V, 50V

Wire Gauge (AWG): 26-22, 30-22, 30-24, 30-28, 32-30

Product Hightlights

Molex's new 1.25mm pitch CLIK-Mate™ series has a superior lock design that offers easier use and better mating retention, compared to

competitive versions. The system also provides about 60% space savings compared to similar dual-lock 2.0mm pitch versions. CLIK-Mate™ 1.25

was designed for applications, such as LCD TVs, that require higher pin count connectors to carry more signal lines in less space. This system

has a similar design to Molex's CLIK-Mate™ 2.0 family and includes many of the same features. 1.25mm (.049") pitch PicoBlade™ system is

designed for high-density harness applications. PicoBlade provides the same 1.0 amperes of current as similar 2.00mm (.079") pitch systems, but

in a more compact design. PicoBlade™ is offered in wire-to-board and wire-to-wire options. The system saves about 45% of PCB space compared

to typical 2.00mm wire-to-board systems. It is a single row system, available in 2 to 15 circuits, with both surface mount and through-hole headers.

Molex's Pico-SPOX™ connector system is an ideal solution for higher current wire-to-board configurations in tight packaging applications. The box

style terminal makes contact with the header pin via two inward-facing dimples to ensure high reliability. Headers are available in vertical and right

angle configurations and offered in tape and reel packaging for high volume pick-and-place production. Polarizing keys on both the headers and

receptacles ensure proper mating. A reliable friction lock feature ensures secure mating retention. The system is rated for 3A max. using AWG #24

wires in a compact 1.50mm pitch design. All parts are lead-free. Molex's 1.25mm (.049") pitch PanelMate™ series is an ultra low-profile connector

system designed for tight packaging applications, requiring profile heights below 2.0mm (.079"). The PanelMate™ name derives from the original

flat-panel LCD display applications for which it was designed.

Features and Benefits

• Reliable two points of contact, high current capable, good electrical connection

• Box-style contact, protects contact area

• Very thin Receptacle design (1.80mm)

• Friction lock provides secure mating

• Polarizing features, ensures proper mating

• Durable blade-type pins, protection

• Locking tang latches into housing window

• Anti-fishhooking contact design to improve handling during harness assembly

Page 1

• Tuning fork style contact design, secure contact, and avoids terminal stubbing

• Two solder tabs for better connection to the PCB

• Low insertion force, easy and quick mating for operators

• Lead-in chamfer to ease mating

• Solder-conducing fillet SMT tail design helps ensure stable solder joints

• Headers fully shrouded to protect pins

• Ultra low mating profile of 1.90mm (.075")

Applications

• Data communication equipment

• Medical equipment

• Automotive

• Office machines

• Alarm systems

• Process controls

• Any application requiring superior mating assurance

• Any low-profile application

• Base Stations

• Digital camera

• Cash dispensers

• Set top boxes

• DVD players

• Patient monitors

• Car radios

• Consumer

• Gaming/Pachinko

• LCD/PDP Televisions

• PCs and monitors

• Handy terminal

• Camcorder

• LCD

Page 2

Bill of Materials

Molex Part No. Description Quantity

50058-8000 PicoBlade™ Crimp Terminal, Female, 32-28 AWG 100

51021-0200 1.25mm (.049") Pitch PicoBlade™ Receptacle, 2 Circuits 3

51021-0400 1.25mm (.049") Pitch PicoBlade™ Receptacle, 4 Circuits 3

51021-0600 1.25mm (.049") Pitch PicoBlade™ Receptacle, 6 Circuits 3

53261-0271 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Right Angle, 2 Circuits 3

53261-0471 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Right Angle, 4 Circuits 3

53261-0671 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Right Angle, 6 Circuits 3

53398-0271 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 2 Circuits 3

53398-0471 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 4 Circuits 3

53398-0671 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 6 Circuits 3

502381-0000 CLIK-Mate™ Male Terminal for 1.25mm (.049") Pitch 100

502380-0200 1.25mm (.049") Pitch, 2 Circuit CLIK-Mate™ Plug 3

502380-0400 1.25mm (.049") Pitch, 4 Circuit CLIK-Mate™ Plug 3

502380-0600 1.25mm (.049") Pitch, 6 Circuit CLIK-Mate™ Plug 3

502382-0270 1.25mm (.049") Pitch, 2 Circuit CLIK-Mate™ Vertical Receptacle 3

502382-0470 1.25mm (.049") Pitch, 4 Circuit CLIK-Mate™ Vertical Receptacle 3

502382-0670 1.25mm (.049") Pitch, 6 Circuit CLIK-Mate™ Vertical Receptacle 3

502386-0270 1.25mm (.049") Pitch, 2 Circuit CLIK-Mate™ Right Angle Receptacle 3

502386-0670 1.25mm (.049") Pitch, 6 Circuit CLIK-Mate™ Right Angle Receptacle 3

502386-0470 1.25mm (.049") Pitch, 4 Circuit CLIK-Mate™ Right Angle Receptacle 3

87421-0000 Pico-Spox™ Female Crimp Terminal Tin, 24-30 AWG 100

87437-0243 1.50mm (.098") Pitch Pico-Spox™ SMT Vertical Header, 4 Circuits 3

87437-0643 1.50mm (.098") Pitch Pico-Spox™ SMT Vertical Header, 6 Circuits 3

87438-0443 1.50mm (.098") Pitch Pico-Spox™ SMT Right Angle Header, 4 Circuits 3

87438-0643 1.50mm (.098") Pitch Pico-Spox™ SMT Right Angle Header, 6 Circuits 3

87439-0400 1.50mm (.098") Pitch Pico-Spox™ Receptacle, 4 Circuits 3

87439-0600 1.50mm (.098") Pitch Pico-Spox™ Receptacle, 6 Circuits 3

50641-8141 PanelMate™ Female Terminal 30-28 AWG 100

51146-0200 1.25mm (.049") Pitch PanelMate™, 2 Circuit, Ultra Low-Profile Receptacle 3

51146-0400 1.25mm (.049") Pitch PanelMate™, 4 Circuit, Ultra Low-Profile Receptacle 3

51146-0600 1.25mm (.049") Pitch PanelMate™, 6 Circuit, Ultra Low-Profile Receptacle 3

53780-0270 1.25mm (.049") Pitch PanelMate™, 2 Circuit, Right Angle Header 3

53780-0670 1.25mm (.049") Pitch PanelMate™, 6 Circuit, Right Angle Header 3

53780-0470 1.25mm (.049") Pitch PanelMate™, 4 Circuit, Right Angle SMT Header 3

87438-0243 1.50mm (.098") Pitch Pico-Spox™ SMT Right Angle Header, 2 Circuits 3

87439-0200 1.50mm (.098") Pitch Pico-Spox™ Receptacle, 2 Circuits 3

87437-0243 1.50mm (.098") Pitch Pico-Spox™ SMT Right Angle Header, 2 Circuits 3

Recommended Molex Tool

Molex Part No. Descripition

Page 3

Part #	87437-0243
Description	WIRE-BOARD CONNECTOR, HEADER,2 POSITION, 1ROW, 1.5MM, SMT
Category	CONNECTOR
Availability	In Stock
Qty	215

Qty	Price
1 - 45	$0.22420
46 - 90	$0.17834
91 - 135	$0.16815
136 - 180	$0.15626
181 +	$0.13928

Manufacturer	Available	Qty
MOLEX	Freelance Stock: 179 Ships Immediately
MOLEX	Freelance Stock: 36 Ships Immediately

87437-0243
