AMP 104550-8

Cross Number:

Item Description: CONN SCKT STRP RCP 80 POS 1.27MM SLDR ST SMD - Rail/Tube

Qty Price
1 - 13 $12.65840
14 - 26 $9.87739
27 - 39 $8.63073
40 - 52 $8.34304
53 + $7.47997



Other Cross Reference

Manufacturer Date Code Qty Available Qty
AMP 9510
  • Freelance Stock: 18
    Ships Immediately


AMP 9301
  • Freelance Stock: 45
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

This document was generated on 05/24/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
0010455081
Status:
Active
Overview: kk
Description: 5.08mm (.200") Pitch KK® Header, Vertical, with Polarizing Backwall, 8 Circuits, Gold
(Au) Plating
Documents:
3D Model Product Specification PS-99020-0087 (PDF)
Drawing (PDF) RoHS Certificate of Compliance (PDF)
Agency Certification
UL E29179
General
Product Family PCB Headers
Series 2599
Application Wire-to-Board
Overview kk
Product Name KK®
Physical
Breakaway No
Circuits (Loaded) 8
Circuits (maximum) 8
Color - Resin Natural
Durability (mating cycles max) 50
First Mate / Last Break No
Flammability 94V-2
Glow-Wire Compliant No
Guide to Mating Part No
Keying to Mating Part None
Lock to Mating Part None
Material - Metal Brass
Material - Plating Mating Gold
Material - Plating Termination Gold
Material - Resin Nylon
Number of Rows 1
Orientation Vertical
PC Tail Length (in) 0.175 In
PC Tail Length (mm) 4.45 mm
PCB Retention None
PCB Thickness Recommended (in) 0.062 In
PCB Thickness Recommended (mm) 1.60 mm
Packaging Type Bag
Pitch - Mating Interface (in) 0.200 In
Pitch - Mating Interface (mm) 5.08 mm
Plating min: Mating (µin) 20
Plating min: Mating (µm) 0.5
Plating min: Termination (µin) 20
Plating min: Termination (µm) 0.5
Polarized to PCB No
Shrouded Partial
Stackable Yes
Surface Mount Compatible (SMC) No
Temperature Range - Operating 0°C to +75°C
Termination Interface: Style Through Hole
Series
image - Reference only
EU RoHS China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
2599Series
Mates With
KK® Crimp Terminal Housing 3001 , 5058
Electrical
Current - Maximum per Contact 7A
Voltage - Maximum 250V
Material Info
Old Part Number 2599M08AG
Reference - Drawing Numbers
Product Specification PS-99020-0087
Sales Drawing SDAE-2599M-N*
This document was generated on 05/24/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
12NEXT
