TWINAX/TRIAX CONNECTORS

150 Series

Miniature 2, 3, 4-lug, & Push-on (TRS)

3150 Series

Miniature Threaded (TTM)

150/3150 Series are concentric twinax/triax connectors for high

density and weight reduction applications. They are commonly

used in digital data bus, video pair, MIL-STD-1553B (primary/

redundant), baseband circuit and in any application for “noise-free

guarded” circuits. TRS/TTM push-on connectors are designed for

blind mate rack and panel applications. The male plug mates with

any TRS/TTM jack and are ideally suited for test cable applications.

Features

• Same size as TPS/TCM connectors

• Solderable Wrench Crimp versions for cables with up to .215"

outer diameter

• Tool Crimp versions for quick termination of cables with up to

.250" outer diameter

• 3-lug, 4-lug, and threaded versions provide different levels of

mechanical stability and keying

• Does not require mechanical alignment for mating

• Meets MIL-C-49142, 48-hour salt spray requirement

• Special plating available to satisfy MIL-STD-1344 500-hour

salt spray requirement

• Push-on versions for test cable applications

• Fewer pieces to assemble

• Hermetically sealed versions available (see page 16)

Mating Twinax Size 8 Contacts

for Digital Data Bus Multi-pin Connectors

Socket....................................... SPC8S-201

Pin............................................. SPC8P-201

1.530

.631/.627

.288

.284

DIA

.276/.273 DIA

.90

.315/.313 DIA

SPC8S-201

1.173

.305/296

.218

DIA

.315/.313 DIA

.90

SPC8P-201

This pair of scoop-proof concentric contacts ts the Size 8 cavity

of MIL-C-38999 series 1, 3, & 4 and MIL-STD-1760 “External Stores”

type connectors.

Features

• Fits MIL-C-17/176-00002 and other twinax/triax cables

• Heat treated beryllium copper spring members

• Gold plated, Full Crimp contacts

Twinax/Triax Connectors / Hermetically Sealed Connectors Twinax/Triax Connectors / 150 Series Intro

Size 8 Mating Contacts

SPC8S-201 Shown

SPC8P-201 Shown

TWINAX/TRIAX CONNECTORS

Mounting Hole: D4.125

Sub-miniature Jacks & Plugs

Sub-miniature concentric twinax/triax connectors increase

packing density up to 246%. They are designed for high density

applications where digital, video pair or baseband noise-free

guarded circuits are required. The 3-lug, 4-lug, and threaded

versions improve mechanical stability and provide “error-free”

redundant data bus capabilities. The wrench crimp version

accommodates cables with other jacket diameters up to .215" and

the tool crimp versions up to .250".

PL155-29 Shown

PL155AC-207 Shown

PLR3155AC-201 Shown

BJ159-29 Shown

CJ150AC-207 Shown

CJ150-29 Shown

“D” mounting holes see page 54.

Mounting Hole: D4.125

.375 HEX NUT

.375 WRENCH FLATS

.080

.748

.460 DIA MAX

.484 DIA MAX OVER KNURL

1.00

1.322

STRAIN RELIEF

.933

.484 DIA MAX

OVER KNURL

1.317

1.77

MAX

.030

CLEAR, 175°C

SHRINKABLE

STRAIN RELIEF

SHRINKABLE

SEALING SLEEVE

(LONG)

.080

.790

.590

.4375-28UNEF-2A

.375 HEX NUT

.500 HEX NUT

.562 HEX

.600 DIA

STRAIN

RELIEF

.4375-28UNEF-2A

.500 HEX

1.164

.590

.375 HEX NUT

.375 WRENCH FLATS

.484 DIA MAX

.080

.790

1.289

.34

.030

SHRINKABLE

STRAIN RELIEF

SHRINKABLE SEALING SLEEVE (LONG)

BJ159AC Shown

Twinax/Triax Connectors / Subminiature Jacks & Plugs

150/3150 Series TRS/TTM

Cable Plug

Wrench Crimp

3-Lug.......................................... PL155-

4-Lug....................................... PL155FL-

Threaded.................................. PL3155-

Cable Plug

Tool Crimp

3-Lug..................................... PL155AC-

4-Lug................................. PL155ACFL-

Threaded............................. PL3155AC-

Right Angle Cable Plug

Tool Crimp

3-Lug................................... PLR155AC-

4-Lug............................... PLR155ACFL-

Threaded........................... PL33155AC-

Bulkhead Jack

Rear Mount, Wrench Crimp

3-Lug.......................................... BJ159-

4-Lug....................................... BJ159FL-

Threaded.................................. BJ3159-

Bulkhead Jack

Rear Mount, Tool Crimp

3-Lug...................................... BJ159AC-

4-Lug................................... BJ159ACFL-

Threaded.............................. BJ3159AC-

Cable Jack

Wrench Crimp

3-Lug.................................. CJ150-

4-Lug............................... CJ150FL-

Threaded.......................... CJ3150-

Cable Jack

Tool Crimp

3-Lug...................................... CJ150AC-

4-Lug................................... CJ150ACFL-

Threaded.............................. CJ3150AC-

Refer to Cable Group Tables, pages 74-91.

TWINAX/TRIAX CONNECTORS

Mounting Hole: D4.125

.295 DIA

.308

1.055

.5625-28UN-2A

.687 HEX NUT

SOLDER POT ACCEPTS

.034 MAX DIA CONDUCTOR

BJ158 Shown

Mounting Hole: D5.190/D4.190 (Threaded)

BJ153 Shown

Mounting Hole: D9.116

BJ157 Shown

(Hermetically sealed version

available, pg.16)

Mounting Hole: D6.187

BJ157F Shown

(S) = Comes with Stainless Steel Phillips #3-56 Pan Head Screws

Maximum Panel Thickness .187

BJ154AC Shown

Mounting Hole: D9.116

“D” mounting holes see page 54.

BJ152 Shown

Mounting Hole: D9.208

BJ150 Shown

Mounting Hole: D4.250

.437 HEX

.375 HEX NUT

ACCEPTS

.034 MAX DIA

CONDUCTOR

.3125-32UNEF-2A

.750

.402

.093 DIA HOLE

1.050

.500

TYP

.485

1.050

.090

.300

DIA

MAX

TYP

SOLDER POT

ACCEPTS .026 DIA

CONDUCTOR

MTG HOLES SEE BELOW

.101

.500 HEX NUT

.4375-28UNEF-2A

SOLDER POT

ACCEPTS

.034 DIA

CONDUCTOR

.140 DIA THRU

1.049

.818

.892

.500 HEX

1.070

.375-32UNEF-2A

.437 HEX NUT

.620

.580

.688 HEX NUT

.030

SHRINKABLE

STRAIN RELIEF

SHRINKABLE

SEALING SLEEVE (LONG)

.750

DIA

1.289

.155

.688 HEX

.5625-28UNEF-2A

.760

.580

1.070

Twinax/Triax Connectors / Subminiature Jacks & Plugs

150/3150 Series TRS/TTM

Twinax/Triax Connectors / Subminiature Bulkhead Jacks

150/3150 Series, TRS/TTM

Front Mount Bulkhead Jack

Rear Mount, Solder Pot

3-Lug................................................. BJ157

4-Lug.............................................. BJ157FL

Threaded......................................... BJ3157

Feed-Through Jack

3-Lug................................................. BJ158

4-Lug.............................................. BJ158FL

Threaded......................................... BJ3158

Bulkhead Jack

Rear Mount, Solder Pot

3-Lug................................................. BJ150

4-Lug.............................................. BJ150FL

Threaded......................................... BJ3150

Bulkhead Jacks

Flange Mount, Solder Pot

3-Lug......................................... BJ157F

4-Lug...................................... BJ157FFL

Threaded................................. BJ3157F

Insulated Bulkhead Jack

Front Mount, Solder Pot

3-Lug................................................. BJ152

4-Lug.............................................. BJ152FL

Threaded......................................... BJ3152

Hole Configuration # of Holes/Type-Dimension

A Dim= .425

2/Clear - .103” Diameter -2C(S)

2/Threaded - .099-56UNF-UB -2T(S)

B Dim= .687

4/Clear - .103” Diameter -4C(S)

4/Threaded - .099-56UNF-UB -4T(S)

Insulated Bulkhead Jack

Rear Mount, Tool Crimp

3-Lug...................................... BJ154AC-

4-Lug.................................. BJ154ACFL-

Threaded.............................. BJ3154AC-

Insulated Feed-Through Jack

3-Lug................................................. BJ153

4-Lug.............................................. BJ153FL

Threaded......................................... BJ3153

Refer to Cable Group Tables, pages 74-91.
