APPENDIX
74
CABLE MANUFACTURER CABLE NUMBER CABLE TYPE WRENCH STYLE CRIMP STYLE JACKET SIZE CONDUCTOR IMPEDANCE
ALCATEL 0960 WL COAX _ -004 0.093 0.011 75
ALCATEL ASNE 0690 WL COAX _ -004 0.093 0.011 75
ALCATEL CDE 003 TWINAX * -204 0.140 0.024 77
ALPHA 8620 COAX -41 -020 0.270 0.041 75
ALPHA 9059 COAX -2 -013 0.242 0.026 75
ALPHA 9102 COAX * -023 0.212 0.032 75
ALPHA 9108 TWINAX -55 * 0.210 0.038 78
ALPHA 9109 TWINAX _ -213 0.252 0.037 100
ALPHA 9158 COAX -21 * 0.165 0.035 53
ALPHA 9174 COAX -5 -003 0.100 0.021 50
ALPHA 9316 COAX -5 -003 0.098 0.021 50
ALPHA 9807 COAX -51 -016 0.304 0.032 75
ALPHA 9817 TWINAX -8 _ 0.327 0.038 100
ALPHA 9830 COAX -2 -013 0.242 0.025 75
ALPHA 9840 COAX -2 -013 0.240 0.025 80
ALPHA 9847 COAX _ -053 0.405 0.064 75
ALPHA 9850 TRIAX -13 TOO LARGE 0.314 0.032 75
ALPHA 9858 COAX -1 -011 0.193 0.036 50
ALPHA 2834/2 TWINAX -45 _ 0.137 0.032 600V
ALPHA 9058C COAX -1 -011 0.194 0.038 50
ALPHA 9179B COAX -5 -004 0.101 0.012 75
ALPHA 9180B COAX -4 * 0.140 0.038 95
ALPHA 9187A COAX -36 -004 0.105 0.010 75
ALPHA 9196A COAX -44 -1 0.070 0.011 50
ALPHA 9804C COAX -41 -020 0.275 0.040 75
ALPHA 9814C TWINAX * -213 0.244 0.038 75
ALPHA 9818C TWINAX -8 _ 0.330 0.037 100
ALPHA 9825C COAX -6A _ 0.400 0.064 75
ALPHA 9861C COAX -1 -011 0.192 0.038 _
ALPHA 9871F COAX * -011 0.182 0.037 50
ALPHA WIRE 2821/2 TWINAX -27 _ 0.138 0.024 600V
AMPHENOL 82-5588 TWINAX -8 _ 0.330 00.39 _
AMPHENOL CNDA 21-1060 COAX -6 -016 _ _ _
AT&T (LUCENT) 733 COAX _ -027 _ _ 75
AT&T (LUCENT) 1735A COAX _ -026 0.128 0.016 75
AT&T (LUCENT) 2735A COAX -22 -026 0.140 0.015 75
AT&T (LUCENT) 734D COAX -63 -025 0.236 0.031 75
AT&T (LUCENT) 735A COAX * -026 0.125 0.016 75
AT&T (LUCENT) NSI 4609 805 13019 COAX -37 * 0.166 0.016 _
AT&T (LUCENT) 724 COAX -6 -016 0.304 0.033 _
AT&T (LUCENT) 728 COAX -6 -016 0.304 0.033 75
AT&T (LUCENT) 731 COAX -2 -015 0.248 0.023 75
AT&T (LUCENT) 730A COAX -2B -015 0.255 0.025
AT&T (LUCENT) 734A COAX -63 -025 0.236 0.031 75
AT&T (LUCENT) KS-19224L2 COAX -31 * 0.116 0.011 _
AT&T (W.E.CO) 16PEVL TWINAX -12 _ 0.460 0.051 _
AT&T (W.E.CO) 754E TWINAX -10 _
0.420 0.040 _
A
T&T (W.E.CO) 760A TWINAX -11 TOO LARGE 0.308 0.025 _
AT&T (W.E.CO) 761A TWINAX -30 0.215 0.021 _
BELDEN 8208 TWINAX -25 _ 0.257 0.047 300V
BELDEN 8212 COAX -2 -014 0.242 0.032 75
BELDEN 8213 COAX -6A -053 0.405 0.064 75
BELDEN 8215 COAX -6E -017 0.332 0.028 75
BELDEN 8216 COAX -5 -003 0.103 0.020 50
Cable Group Table
Note: * = Special contact customer service
For a complete listing please refer to the online catalog.
