Schematics
International Laminated Power Transformers
• 115V/230V Dual Primary • Power 2.5VA to 56VA
• Class B (130°C) File No. E92957 • TUV File No. 20650818 (EN61558-1,-2 -6)
• 3500Vrms HiPot (Pri:Sec) • UL1411 File NO. E138028 (Construction Only)
• UL94V-0 Flammability
• UL506 File No. E79781
• Non-Inherently Limited
• RoHS Compliant
www. tamur ac or p. com
Linear Power Transformers
L
H
A B
A
F
E
C
G
W
A
B
A
.187 MIN
(4.75)
VA
MOUNTING
MTG. PIN LBS
(SIZE)
L W H A B C
E F G
SCREWS
SQUARE (KG.)
2.5 1.625 1.43 1.125 .200 .250 1.000 1.063 — — 2X#4 .025 .25
(41.3) (36.3) (28.6) (5.1) (6.4) (25.4) (27.0) (2X M3) (.635) (.11)
5.0 1.625 1.43 1.375 .200 .400 1.000 1.063 — — 2X#4 .025 .37
(41.3) (36.3) (34.9) (5.1) (10.2) (25.4) (27.0) (2X M3) (.635) (.17)
10.0 1.875 1.563 1.42 .200 .400 1.140 1.250 — — 2X#4 .036 .53
(47.6) (39.7) (36.1) (5.1) (10.2) (29.0) (31.8) (2X M3) (.914) (.24)
20.0 2.250 1.875 1.625 .400 .400 1.460 1.500 — — 2X#4 .036 .90
(57.2) (47.6) (41.3) (10.2) (10.2) (37.1) (38.1) (2X M3) (.914) (.41)
30.0 2.625 2.188 1.563 .550 .275 1.680 — 2.19 1.75 4X#4 .045 1.15
(66.7) (55.6) (39.7) (14.0) (7.0) (42.7) (55.6) (44.5) (4X M3) (1.14) (.52)
56.0 3.000 2.50 1.845 .600 .300 1.900 — 2.50 2.00 4X#6 .045 1.70
(76.2) (63.5) (46.9) (15.2) (7.6) (48.3) (63.5) (50.8) (4X M5) (1.14) (.77)
Dimensions Inches (mm)
Packaging:
Size Tube Box
2.5 10 40
5.0 9 54
10.0 8 40
Size Box
20.0 20
30.0 20
56.0 10
115/230V
50/60 H
z
6
4
3
1
7
9
10
12
PART
NUMBER
VA
(SIZE)
SECONDARY RMS RATING
PARALLEL CONNECTED
SERIES CONNECTED
VOLTS
AMPS VOLTS AMPS
PL2.5-10-130B
2.5 5.0 0.50 10.0 CT 0.25
PL5.0-10-130B
5.0 5.0 1.00 10.0 CT 0.50
PL10-10-130B
10.0 5.0 2.00 10.0 CT 1.00
PL20-10-130B
20.0 5.0 4.00 10.0 CT 2.00
PL30-10-130B
30.0 5.0 6.00 10.0 CT 3.00
PL56-10-130B
56.0 5.0 11.20 10.0 CT 5.60
PL2.5-12-130B
2.5 6.3 0.40 12.6 CT 0.20
PL5.0-12-130B
5.0 6.3 0.80 12.6 CT 0.40
PL10-12-130B
10.0 6.3 1.60 12.6 CT 0.80
PL20-12-130B
20.0 6.3 3.20 12.6 CT 1.60
PL30-12-130B
30.0 6.3 4.80 12.6 CT 2.40
PL56-12-130B
56.0 6.3 8.80 12.6 CT 4.40
PL2.5-16-130B
2.5 8.0 0.30 16.0 CT 0.15
PL5.0-16-130B
5.0 8.0 0.62 16.0 CT 0.31
PL10-16-130B
10.0 8.0 1.25 16.0 CT 0.62
PL20-16-130B
20.0 8.0 2.50 16.0 CT 1.25
PL30-16-130B
30.0 8.0 3.80 16.0 CT 1.90
PL56-16-130B
56.0 8.0 7.00 16.0 CT 3.50
PL2.5-20-130B
2.5 10.0 0.24 20.0 CT 0.12
PL5.0-20-130B
5.0 10.0 0.50 20.0 CT 0.25
PL10-20-130B
10.0 10.0 1.00 20.0 CT 0.50
PL20-20-130B
20.0 10.0 2.00 20.0 CT 1.00
PL30-20-130B
30.0 10.0 3.00 20.0 CT 1.50
PL56-20-130B
56.0 10.0 5.60 20.0 CT 2.80
PL2.5-24-130B
2.5 12.0 0.20 24.0 CT 0.10
PL5.0-24-130B
5.0 12.0 0.42 24.0 CT 0.21
PL10-24-130B
10.0 12.0 0.84 24.0 CT 0.42
PL20-24-130B
20.0 12.0 1.66 24.0 CT 0.83
PL30-24-130B
30.0 12.0 2.50 24.0 CT 1.25
PL56-24-130B
56.0 12.0 4.66 24.0 CT 2.33
PL2.5-28-130B
2.5 14.0 0.18 28.0 CT 0.09
PL5.0-28-130B
5.0 14.0 0.36 28.0 CT 0.18
PL10-28-130B
10.0 14.0 0.72 28.0 CT 0.36
PL20-28-130B
20.0 14.0 1.44 28.0 CT 0.72
PL30-28-130B
30.0 14.0 2.12 28.0 CT 1.06
PL56-28-130B
56.0 14.0 4.00 28.0 CT 2.00
PL2.5-36-130B
2.5 18.0 0.14 36.0 CT 0.07
PL5.0-36-130B
5.0 18.0 0.28 36.0 CT 0.14
PL10-36-130B
10.0 18.0 0.56 36.0 CT 0.28
PL20-36-130B
20.0 18.0 1.12 36.0 CT 0.56
PL30-36-130B
30.0 18.0 1.64 36.0 CT 0.82
PL56-36-130B
56.0 18.0 3.12 36.0 CT 1.56
