Part Number:
0787311002
Status:
Active
Overview: DDR4 DIMM Sockets
Description: DDR4 DIMM Socket, Vertical Press-Fit, 30µm Gold Plating, 288 Circuits, PCB
Thickness 1.80mm (.071"), Black Housing, Black Latch
Documents:
Drawing (PDF) RoHS Certificate of Compliance (PDF)
Application Specification AS-78731-003 (PDF)
Agency Certification
CSA 1409726
UL E29179
General
Product Family Memory Module Sockets
Series 78731
Comments Black Housing, Black Latch
Component Type Socket
Electrical Model Yes
JEDEC Outline MO-309
Overview DDR4 DIMM Sockets
Product Name DDR4 DIMM
UPC 887191484396
Physical
Circuits (Loaded) 288
Circuits (maximum) 288
Color - Resin Black
Durability (mating cycles max) 25
Entry Angle Vertical (Top Entry)
Flammability 94V-0
Keying to Mating Part Yes
Material - Metal Copper Alloy
Material - Plating Mating Gold over Nickel
Material - Plating Termination Tin over Nickel
Material - Resin Nylon
Net Weight 7.416/g
PCB Retention None
PCB Thickness - Recommended 1.80mm
Packaging Type Tray
Pitch - Mating Interface 0.85mm
Pitch - Termination Interface 0.85mm
Plating min - Mating 0.762µm
Plating min - Termination 0.381µm
Temperature Range - Operating -55°C to +85°C
Termination Interface: Style Press-Fit
Electrical
Current - Maximum per Contact 0.75A
Voltage - Maximum 29V AC (RMS)/DC
Solder Process Data
Duration at Max. Process Temperature (seconds) 005
Lead-freeProcess Capability SMC&WAVE
Max. Cycles at Max. Process Temperature 002
Process Temperature max. C 260
Series image - Reference only
EU ELV
Not Relevant
EU RoHS China RoHS
Compliant
REACH SVHC
Contains SVHC(2015
June 15): No
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS Green Image
ELV Not Relevant
Search Parts in this Series
78731 Series
