17
Radial Leads/SkyCap
®
X7R Dielectric
For other styles, voltages, tolerances and lead lengths see Part No. Codes or contact factory.
*Other capacitance values available upon special request.
NOTE: Capacitance Ranges available for SR12 same as SR15
SR62 same as SR21
SR64 same as SR30
SR89 same as SR21
AVX Style SR15 SR20 SR21 SR22 SR27 SR30 SR40 SR50
AVX “Insertable” SR07 SR29 SR59 N/A N/A SR65 SR75 N/A
Width 3.81 5.08 5.08 5.08 6.604 7.62 10.16 12.70
(W) (.150) (.200) (.200) (.200) (.260) (.300) (.400) (.500)
Height 3.81 5.08 5.08 5.08 6.35 7.62 10.16 12.70
(H) (.150) (.200) (.200) (.200) (.250) (.300) (.400) (.500)
Thickness 2.54 3.175 3.175 3.175 4.06 3.81 3.81 5.08
(T) (.100) (.125) (.125) (.125) (.160) (.150) (.150) (.200)
Lead Spacing 2.54 2.54 5.08 6.35 7.62 5.08 5.08 10.16
(L.S.) (.100) (.100) (.200) (.250) (.300) (.200) (.200) (.400)
Lead Diameter .508 .508 .508 .508 .508 .508 .508 .635
(L.D.) (.020) (.020) (.020) (.020) (.020) (.020) (.020) (.025)
Cap. in.* Industry Preferred WVDC WVDC WVDC WVDC WVDC WVDC WVDC WVDC
pF Values in Blue 200 100 50 200 100 50 200 100 50 100 50 100 50 200 100 50 200 100 50 200 100 50
470 SR
-----
C471KAA
1000 SR155C102KAA
1500 SR
-----
C152KAA
2200 SR
-----
C222KAA
3300 SR
-----
C332KAA
4700 SR
-----
C472KAA
6800 SR
-----
C682KAA
10,000 SR215C103KAA
15,000 SR
-----
C153KAA
22,000 SR
-----
C223KAA
33,000 SR
-----
C333KAA
47,000 SR
-----
C473KAA
68,000 SR
-----
C683KAA
100,000 SR215C104KAA
150,000 SR
-----
C154KAA
220,000 SR215C224KAA
330,000 SR
-----
C334KAA
390,000 SR
-----
C394KAA
470,000 SR305C474KAA
1.0 µF SR305C105KAA
2.2 µF SR405C225KAA
2.7 µF SR505C275KAA
4.7 µF SR505C475KAA
= Industry preferred values
= SR20 only
= Extended range
= Extended range, SR20 only
= Extended range with 0.150" thickness maximum
SIZE AND CAPACITANCE SPECIFICATIONS
EIA Characteristic Dimensions: Millimeters (Inches)
