Aluminum Electrolytic Capacitors/ NHG
– EEE-100 –
■ Standard Prod ucts
W.V.
Cap.
(±20 %)
Case size Specifi cation Lead Length
Part No.
Min. Packaging Q'ty
Dia. Length
Ripple
Current
(120 Hz)
(+105 °C)
tan
δ
(120 Hz)
(+20 °C)
Endur-
ance
Lead
Dia.
Lead Space
Straight
Leads
Taping
Straight
Taping
✽
B
Taping
✽
i
(V) (µF) (mm) (mm)
(mA r.m.s.)
(hours) (mm) (mm) (mm) (mm) (pcs) (pcs)
6.3
220 5 11 140 0.28 1000 0.5 2.0 5.0 2.5
ECA0JHG221( )
200 2000
470 6.3 11.2 2300.281000 0.5 2.5 5.0 2.5
ECA0JHG471( )
200 2000
1000 8 11.5 380 0.28 1000 0.6 3.5 5.0
ECA0JHG102( )
200 1000
2200 10 16 710 0.302000 0.6 5.0 5.0
ECA0JHG222( )
200 500
3300 10 20 840 0.322000 0.6 5.0 5.0
ECA0JHG332( )
200 500
4700 12.5 20 1090 0.34 2000 0.6 5.0 5.0
ECA0JHG472( )
200 500
6800 12.5 25 1350 0.38 2000 0.6 5.0 5.0
ECA0JHG682( )
200 500
10000 16 25 1650 0.46 2000 0.8 7.5 7.5
ECA0JHG103( )
100 250
15000 16 31.5 2010 0.56 2000 0.8 7.5
ECA0JHG153
100
22000 18 35.5 2350 0.70 2000 0.8 7.5
ECA0JHG223
50
10
330 6.3 11.2 2000.241000 0.5 2.5 5.0 2.5
ECA1AHG331( )
200 2000
470 8 11.5 250 0.241000 0.6 3.5 5.0
ECA1AHG471( )
200 1000
1000 10 12.5 460 0.24 2000 0.6 5.0 5.0
ECA1AHG102( )
200 500
2200 10 20 760 0.262000 0.6 5.0 5.0
ECA1AHG222( )
200 500
3300 12.5 20 1000 0.28 2000 0.6 5.0 5.0
ECA1AHG332( )
200 500
4700 12.5 25 1260 0.30 2000 0.6 5.0 5.0
ECA1AHG472( )
200 500
6800 16 25 1570 0.34 2000 0.8 7.5 7.5
ECA1AHG682( )
100 250
10000 16 31.5 1890 0.42 2000 0.8 7.5
ECA1AHG103
100
15000 18 35.5 2180 0.52 2000 0.8 7.5
ECA1AHG153
50
16
100 5 11 110 0.20 1000 0.5 2.0 5.0 2.5
ECA1CHG101( )
200 2000
220 6.3 11.2 180 0.20 1000 0.5 2.5 5.0 2.5
ECA1CHG221( )
200 2000
330 8 11.5 260 0.201000 0.6 3.5 5.0
ECA1CHG331( )
200 1000
470 8 11.5 310 0.201000 0.6 3.5 5.0
ECA1CHG471( )
200 1000
1000 10 16 560 0.20 2000 0.6 5.0 5.0
ECA1CHG102( )
200 500
2200 12.5 20 920 0.222000 0.6 5.0 5.0
ECA1CHG222( )
200 500
3300 12.5 25 1170 0.24 2000 0.6 5.0 5.0
ECA1CHG332( )
200 500
4700 16 25 1480 0.26 2000 0.8 7.5 7.5
ECA1CHG472( )
100 250
6800 16 31.5 1780 0.30 2000 0.8 7.5
ECA1CHG682
100
10000 18 35.5 2060 0.38 2000 0.8 7.5
ECA1CHG103
50
25
47 5 11 91 0.161000 0.5 2.0 5.0 2.5
ECA1EHG470( )
200 2000
100 6.3 11.2 130 0.161000 0.5 2.5 5.0 2.5
ECA1EHG101( )
200 2000
220 8 11.5 230 0.161000 0.6 3.5 5.0
ECA1EHG221( )
200 1000
330 8 11.5 310 0.161000 0.6 3.5 5.0
ECA1EHG331( )
200 1000
470 10 12.5 380 0.16 2000 0.6 5.0 5.0
ECA1EHG471( )
200 500
1000 10 20 680 0.16 2000 0.6 5.0 5.0
ECA1EHG102( )
200 500
2200 12.5 25 1090 0.18 2000 0.6 5.0 5.0
ECA1EHG222( )
200 500
3300 16 25 1400 0.20 2000 0.8 7.5 7.5
ECA1EHG332( )
100 250
4700 16 31.5 1750 0.22 2000 0.8 7.5
ECA1EHG472
100
6800 18 35.5 2040 0.26 2000 0.8 7.5
ECA1EHG682
50
35
47 5 11 90 0.141000 0.5 2.0 5.0 2.5
ECA1VHG470( )
200 2000
100 6.3 11.2 150 0.141000 0.5 2.5 5.0 2.5
ECA1VHG101( )
200 2000
220 8 11.5 270 0.141000 0.6 3.5 5.0
ECA1VHG221( )
200 1000
330 10 12.5 350 0.14 2000 0.6 5.0 5.0
ECA1VHG331( )
200 500
470 10 16 460 0.14 2000 0.6 5.0 5.0
ECA1VHG471( )
200 500
1000 12.5 20 810 0.14 2000 0.6 5.0 5.0
ECA1VHG102( )
200 500
2200 16 25 1260 0.16 2000 0.8 7.5 7.5
ECA1VHG222( )
100 250
3300 16 31.5 1610 0.18 2000 0.8 7.5
ECA1VHG332
100
4700 18 35.5 1910 0.20 2000 0.8 7.5
ECA1VHG472
50
· When requesting taped product, please put the letter "B" or "i" between the "( )". Lead wire pitch B=5 mm, 7.5 mm, i=2.5 mm.
· Please refer to the page of “Taping Dimensions”.
