C3225X5R0J107M

Part # C3225X5R0J107M
Description Cap Ceramic 100uF 6.3V X5R 20% SMD 1210 85C Plastic T/R
Additional Information:


Category CAPACITOR
Availability Out of Stock
Qty 0
Qty Price
1 + $1.82178
