RATINGS & PART NUMBER REFERENCE: STABLE TEMPERATURE CHARACTERISTICS - X7R
Gold Max
CERAMIC CONFORMALLY COATED/RADIAL
“STANDARD & HIGH VOLTAGE GOLD MAX”
Cap Cap
Cap Code Tol
25 50 100 200 250 500 1k 25 50 100 200 250 500 1k 1.5k 2k 25 50 100 200 250 500 1k 1.5k 2k 2.5k 3k
10pF 100 K,M,P,Z
12 120 K,M,P,Z
15 150 K,M,P,Z
18 180 K,M,P,Z
22 220 K,M,P,Z
27 270 K,M,P,Z
33 330 K,M,P,Z
39 390 K,M,P,Z
47 470 K,M,P,Z
56 560 K,M,P,Z
68 680 K,M,P,Z
82 820 K,M,P,Z
100 101 K,M,P,Z
120 121 K,M,P,Z
150 151 K,M,P,Z
180 181 K,M,P,Z
220 221 K,M,P,Z
270 271 K,M,P,Z
330 331 K,M,P,Z
390 391 K,M,P,Z
470 471 K,M,P,Z
560 561 K,M,P,Z
680 681 K,M,P,Z
820 821 K,M,P,Z
1000 102 K,M,P,Z
1200 122 K,M,P,Z
1500 152 K,M,P,Z
1800 182 K,M,P,Z
2200 222 K,M,P,Z
2700 272 K,M,P,Z
3300 332 K,M,P,Z
3900 392 K,M,P,Z
4700 472 K,M,P,Z
5600 562 K,M,P,Z
6800 682 K,M,P,Z
8200 822 K,M,P,Z
.010uF 103 K,M,P,Z
.012 123 K,M,P,Z
.015 153 K,M,P,Z
.018 183 K,M,P,Z
.022 223 K,M,P,Z
.027 273 K,M,P,Z
.033 333 K,M,P,Z
.039 393 K,M,P,Z
.047 473 K,M,P,Z
.056 563 K,M,P,Z
.068 683 K,M,P,Z
.082 823 K,M,P,Z
.10 104 K,M,P,Z
.12 124 K,M,P,Z
.15 154 K,M,P,Z
.18 184 K,M,P,Z 22
.22 224 K,M,P,Z 22
.27 274 K,M,P,Z 22
.33 334 K,M,P,Z 22
.39 394 K,M,P,Z 222
.47 474 K,M,P,Z 222
.56 564 K,M,P,Z 222
.68 684 K,M,P,Z 222
.82 824 K,M,P,Z 222
1.0 105 K,M,P,Z 222
1.2 125 K,M,P,Z 22 2 2 2
1.5 155 K,M,P,Z 22
1.8 185 K,M,P,Z 22
2.2 225 K,M,P,Z 22
2.7 275 K,M,P,Z
3.3 335 K,M,P,Z
3.9 395 K,M,P,Z
4.7 475 K,M,P,Z 1 1
5.6 565 K,M,P,Z 1
6.8 685 K,M,P,Z 1
10.0 106 K,M,P,Z 1
(1) Thickness max = 0.160" (4.064mm)
(2) Requires straight leads (all other C33X's require bent leads)
C32X
Style
C31X
WVDC WVDCWVDC
C33X
For packaging information, see pages 47 and 48.
