C2012C0G1H101J

Part # C2012C0G1H101J
Description Cap Ceramic 100pF 50V C0G 5%SMD 0805 125C
Additional Information:


Category CAPACITOR
Availability In Stock
Qty 359
Qty Price
1 + $0.02998
Manufacturer Available Qty
TDK Corporation
Date Code: 1021
