Configuration Register (CONFIG-1)
Functional Description
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Configuration Register (CONFIG-1) 199
LVIPWR — LVI Power Enable Bit
LVIPWR enables the LVI module. (See Low Voltage Inhibit (LVI) on
page 229).
1 = LVI module power enabled
0 = LVI module power disabled
SSREC — Short Stop Recovery Bit
SSREC enables the CPU to exit stop mode with a delay of 32
CGMXCLK cycles instead of a 4096-CGMXCLK cycle delay. (See
Stop Mode on page 164).
1 = Stop mode recovery after 32 CGMXCLK cycles
0 = Stop mode recovery after 4096 CGMXCLK cycles
NOTE: If using an external crystal oscillator, do not set the SSREC bit.
COPL — COP Long Timeout
COPL enables the shorter COP timeout period. (See Computer
Operating Properly (COP) on page 223).
1 = COP timeout period is 2
13
– 2
4
CGMXCLK cycles
0 = COP timeout period is 2
18
– 2
4
CGMXCLK cycles
STOP — STOP Instruction Enable Bit
STOP enables the STOP instruction.
1 = STOP instruction enabled
0 = STOP instruction treated as illegal opcode
COPD — COP Disable Bit
COPD disables the COP module. (See Computer Operating
Properly (COP) on page 223).
1 = COP module disabled
0 = COP module enabled
Extra care should be exercised when using this emulation part for
development of code to be run in ROM AZ, AB or AS parts that the
options selected by setting the CONFIG-1 register match exactly
the options selected on any ROM code request submitted. The
enable/disable logic is not necessarily identical in all parts of the
AS and AZ families. If in doubt, check with your local field
applications representative.
Configuration Register (CONFIG-1)
Technical Data MC68HC908AZ60A — Rev 2.0
200 Configuration Register (CONFIG-1) MOTOROLA
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Configuration Register (CONFIG-2) 201
Technical Data — MC68HC908AZ60A
Section 12. Configuration Register (CONFIG-2)
12.1 Contents
12.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
12.3 Functional Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
12.2 Introduction
This section describes the configuration register (CONFIG-2). This
register contains bits that configure these options:
Configures the device to either the MC68HC08AZxx emulator or
the MC68HC08ASxx emulator
Disables the CAN module
12.3 Functional Description
The configuration register is a write-once register. Out of reset, the
configuration register will read the default. Once the register is written,
further writes will have no effect until a reset occurs.
Address: $FE09
Bit 7654321Bit 0
Read:
EEDIV
CLK
R R MSCAND
AT60A
RRAZxx
Write: R
Reset:00011000
R= Reserved
Figure 12-1. Configuration Register (CONFIG-2)
