Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

ERM
Or
LRA
OUT+
OUT-
100k
100k
470 pF
470 pF
Ch1-Ch2
(Differential)
Oscilloscope
Ch1
Ch2
ERM
or
LRA
OUT+
OUT-
Ch1-Ch2
(Differential)
with Digital
Low-Pass Filter
Oscilloscope
Ch1
Ch2
www.ti.com
MSP430 Control and Firmware
Figure 15. Measuring the DRV2603 Output with a Digital Low-pass Filter
An analog 1st order, low-pass, RC filter can also be used; however, care must be taken not to use a filter
impedance that is too low. Low filter impedance can affect the back-EMF of the actuator and interfere with
the auto-resonance detection algorithm. See the recommend values in Figure 16.
Figure 16. Measuring the DRV2603 Output Signal with an Analog Low-pass Filter
5 MSP430 Control and Firmware
The DRV2603EVM-CT is controlled by a programmable MSP430. This section contains information for
programming and controlling the board using the MSP430.
5.1 Additional Hardware Modes
Additional modes are available on the DRV2603EVM-CT that provide increased board control and
functionality. The additional modes are not available in “demo” mode, but can be access by switching to
“binary counting mode”. In “binary counting mode” the mode LEDs count in binary (32 modes) rather than
in “demo” mode format (only 6 modes including off).
5.1.1 Enter Binary Counting Mode
To enter “binary counting mode” and access the additional modes:
1. Press and hold the increment mode button (“+”) for approximately 3 seconds.
2. Release the button when the actuator buzzes and the mode LEDs flash.
3. Select from the “binary counting modes” using the “+” and “-“ buttons.
All modes, including “demo” modes, are available in binary counting mode, see Table 3 for a description.
5.1.2 Exit Binary Counting Mode
To exit “binary counting mode” and return to “demo” mode:
1. Press and hold the decrement mode button (“-“) for approximately 3 seconds.
2. Release the button when the actuator buzzes and mode LEDs flash.
3. Select from the “demo” modes using the “+” and “-“ buttons.
13
SLOU340A–May 2012–Revised May 2012 DRV2603 ERM/LRA Haptic Driver Evaluation Kit
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
MSP430 Control and Firmware
www.ti.com
5.1.3 Binary Counting Modes
Table 3 lists the modes available in “binary counting mode”. The same modes in “demo” mode are present
in “binary counting mode”.
Table 3. Binary Counting Modes
Mode Button Description Actuator Mode Notes
Mode 0 Ramp and Clicks. See Table 1 Mode 0.
Mode 1 Concentration Game. See Table 1 Mode 5.
Mode 2 ERM Clicks. See Table 1 Mode 4.
B1 Disable Amplifier External PWM - Apply an
external PWM source to
B2 Enable DRV2603 LRA (Auto-Resonance On)
Mode 3
the PWM testpoint, use
External PWM
B3 Enable DRV2603 LRA (Auto-Resonance Off)
MSP430 for hardware
LEDs: 00011
configuration. Remove
B4 Enable DRV2603 ERM
jumper JP1.
Mode 4 LRA Keyboard and Mouse Effects. See Table 1 Mode 3.
B1 Disable Amplifier External PWM / External
Mode 5 Enable - Apply an external
B2 Enable DRV2603 LRA (Auto-Resonance On)
External PWM and External PWM source and enable
B3 Enable DRV2603 LRA (Auto-Resonance Off)
Enable signal. Enable pin on
LEDs: 00101 MSP430 is Hi-Z. Remove
B4 Enable DRV2603 ERM
jumper JP1.
B1 Begin Life Test Life Test (2 seconds on, 1
second off) - life test
B2 Test Buzz
repeats infinite times and
Mode 6
Decrease output voltage
board must be powered
B3
Life Test (LRA) LRA (Auto-resonance On)
(+1 increment)
down to stop. Increment /
LEDs: 00110
Decrement amplitude using
Increase output voltage (+1
B3 and B4. Test new
B4
increment)
amplitude using B2.
B1 Begin Life Test Life Test (Infinite Buzz) -
board must be powered
B2 Test Buzz
down to stop buzz.
Mode 7
Decrease output voltage
Increment / Decrement
B3
Life Test Buzz (LRA) LRA (Auto-resonance On)
(+1 increment)
amplitude using B3 and B4.
LEDs: 00111
Test new amplitude using
Increase output voltage (+1
B2 before beginning life
B4
increment)
test.
Mode 8 LRA Clicks. See Table 1 Mode 2
B1 Alert (Auto-resonance On) LRA (Auto-resonance On) Vary the auto-resonance off
output frequency and see
B2 Alert (Auto-resonance Off)
Mode 9
the change in vibration
Auto-resonance off
B3 Decrease output frequency
force over frequency.
frequence adjust
LRA (Auto-resonance Off)
Compare B2 (auto-
LEDs: 01001
resonance off) with B1
B4 Increase output frequence
(auto-resonance on).
B1 Begin Life Test Life Test (Infinite Buzz) -
board must be powered
B2 Test Buzz
down to stop buzz.
Mode 10
Decrease output voltage
Increment / Decrement
B3
Life Test Buzz (ERM) ERM
(+1 increment)
amplitude using B3 and B4.
LEDs: 01010"
Test new amplitude using
Increase output voltage (+1
B2 before beginning life
B4
increment)
test.
Mode 16 Alerts. See Table 1 Mode 1.
14
DRV2603 ERM/LRA Haptic Driver Evaluation Kit SLOU340A–May 2012–Revised May 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
www.ti.com
MSP430 Control and Firmware
5.2 Modifying or Reprogramming the Firmware
The MSP430 firmware on the DRV2603EVM-CT can be modified or reprogrammed to create new haptic
effects or behaviors. Find the latest firmware source code and binaries on TI.com. Follow the instructions
below to modify or reprogram the DRV2603EVM-CT.
1. Purchase one of the following MSP430G2553 compatible programmers:
• EZ430-F2013 (recommended)
• MSP-EXP430G2 (recommended) - requires the additional purchase of a header for J4
– Digi-Key: ED8650-ND
– Mouser: 575-500201
• MSP430-FET430UIF - requires a JTAG to Spy-Bi-Wire adapter (MSP-JTAGSBW if available)
2. Download and install Code Compose Studio (CCS) or IAR Embedded Workbench IDE.
3. Download the DRV2603EVM-CT source code and binaries from TI.com.
4. Connect the programmer to an available USB port.
5. Connect the programmer to the “SBW” header on the DRV2603EVM-CT.
6. In CCS,
(a) Open the project file by selecting Project > Import Existing CCS Project.
(b) Select Browse and navigate to the DRV2603EVM-CT project folder, then press OK.
(c) Select the checkbox next to the DRV2603EVM-CT project in the “Discovered projects” window and
then press “Finish”.
(d) Before compiling, navigate to Project > Properties > Build > MSP430 Compiler > Advanced Options
> Language Options and make sure the checkbox for “Enable support for GCC extensions (--gcc)”
is checked.
7. In IAR,
(a) Create a new MSP430 project in IAR,
(b) Select the MSP430G2553 device,
(c) Copy the files in the project folder downloaded from TI.com to the new project directory.
15
SLOU340A–May 2012–Revised May 2012 DRV2603 ERM/LRA Haptic Driver Evaluation Kit
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
PREVIOUS12345678910NEXT
